Bevel impact test

Update：2020/1/15 22:50:33??????Click on：

Project Introduction

　　Bevel impact test

　　Bevel impact is mainly used to evaluate the ability of the package to withstand impact and the ability to protect the inner package. Bevel impact method with the National standard, ISO, ASTM, etc., although is not the same as the standard method is the same, will test the product on the cart, trolley along a guide rail to the Angle of tilt 10 a certain speed impact and guide rail vertical baffle, can also be in the surface of the baffle and the impact of the test sample surface, edges between an obstruction placed right on the impact of the simulation under special circumstances.

　　Bevel impact is used to simulate the impact between package and baffle caused by train grouping hump slip and vehicle braking. In ISTA, ASTM D4169, GB/T 4857 and other standards, slant impact test is involved in large packages, and the impact speed required by different standards will vary. For example, the impact speed required by ISTA 3E-17 is not lower than 48in/s, while ASTM D4169 has 5.75ft/s, 4.0ft/s, and 3.0ft/s. This test mainly considers the strength of the outer packing and the buffer performance of the inner packing material. Packaging rigidity is too big, easy to crack, impact energy absorption is small and even amplified to the packaging of internal products. If the package is too soft and easy to deform, the product may be damaged by direct impact on the baffle.

　　In order to reduce the damage of bevel impact, it is very important to choose the right packaging.

　　Fugang Industrial Testing Services(Suzhou) Co., Ltd. is a professional packaging transportation testing laboratory, focusing on bevel impact test, bevel impact test, horizontal impact test,the FTS TEAM strives to select the right packaging for users, and provides positive support for users to actively deal with the packaging requirements of foreign e-commerce companies and product registration and packaging verification. If you need packing transportation test service, please contact us: .

　　Please indicate the source: The FTS TEAM www.zztdsm.cn
